Fabric Thickness Meter Digital Fabrics Thickness Gauge Textile Thickness Meter Filter Cloth Non-woven Thickness Tester Machine

Brand Name : LONROY

Place of Origin : Guangdong, China

MOQ : 1

Thickness range : 0.01mm - 25.00mm; 0.001mm - 25mm; 0.01mm - 50mm; 0.001mm - 50mm

Minimum graduation : 0.01mm; 0.001mm

Pressing foot diameter : Φ11.28mm, Φ50.48mm, Φ56.42mm, Φ112.84mm

Pressing foot area : 100mm², 2000mm², 2500mm², 10000mm²

Weighting weights : 5cN, 10cN, 50cN, 100cN, 200cN, 500cN

Weight application time : 10 seconds, 30 seconds

Power supply : AC 220V ± 10% 50Hz

Net dimension : 410mm × 160mm × 395mm

Net weight : 25kg

Wooden box dimensions : 600mm × 480mm × 330mm

Protection class : IP56

Voltage : 220 V

Applicable standard : GB/T3820

Pressing foot types : 4 types

Weight types : 6 types

Contact Now

Fabric Thickness Meter Digital Fabrics Thickness Gauge Textile Thickness Meter Filter Cloth Non-woven Thickness Tester Machine

Product Description

I. Introduction

This instrument is mainly used for measuring the thickness of various textiles and textile products under different pressures, and it can also be used for measuring the thickness of other uniform thin materials.

2. Applicable standard: GB/T3820.

Fabric Thickness Meter Digital Fabrics Thickness Gauge Textile Thickness Meter Filter Cloth Non-woven Thickness Tester Machine

Technical Specification

Thickness Testing Range

0.01mm - 25.00mm; 0.001mm - 25mm; 0.01mm - 50mm; 0.001mm - 50mm

Minimum Graduation Value

0.01mm; 0.001mm

Pressing Foot Diameter and Area

Diameter: Φ11.28mm, Φ50.48mm, Φ56.42mm, Φ112.84mm; Area: 100mm², 2000mm², 2500mm², 10000mm²

Weighting Weights

5cN, 10cN, 50cN, 100cN, 200cN, 500cN (a total of 6 types)

Weight Application Time

10 seconds, 30 seconds

Power Supply

AC 220V ± 10% 50Hz

Net Dimension

410mm × 160mm × 395mm (Note: "Net volume" is adjusted to "Net dimension" based on parameter type, referring to the device's physical size rather than volume)

Net Weight

25kg

Internal Dimensions of Wooden Box

600mm × 480mm × 330mm

Fabric Thickness Meter Digital Fabrics Thickness Gauge Textile Thickness Meter Filter Cloth Non-woven Thickness Tester MachineFabric Thickness Meter Digital Fabrics Thickness Gauge Textile Thickness Meter Filter Cloth Non-woven Thickness Tester MachineFabric Thickness Meter Digital Fabrics Thickness Gauge Textile Thickness Meter Filter Cloth Non-woven Thickness Tester MachineFabric Thickness Meter Digital Fabrics Thickness Gauge Textile Thickness Meter Filter Cloth Non-woven Thickness Tester MachineFabric Thickness Meter Digital Fabrics Thickness Gauge Textile Thickness Meter Filter Cloth Non-woven Thickness Tester Machine
